1、 滾筒材質為不銹鋼結構，各傳動軸采用高精度特殊鋼管精加工而成，有效的保證了床單被套熨燙質量和燙帶的不偏不跑。Stainless steel raw material of roller contracture, the drive shaft with high precision special steel pipe finishing, effectively ensure the quality of the bed cover, sheet ironing without belt slant.
2、 大加熱面積，提高躺平速度，充分利用了熱能，降低了使用成本。Well heating area and speed, taking full advantage of heat energy and saving cost.
3、 變頻調速，一體式鏈條傳動設計，結構簡單、傳動平穩。故障率低，維護方便。 Frequency speed control, one-completed chain transmission design, simple construction, stable transmission, low failure rate, convenient maintenance.
4、 組合式多滾筒設計，方便用戶隨產量增加而升級設備，增加滾筒。The design of modular multi roller makes it convenient for customers to upgrade the machine.
5、 采用漲緊輪設計，可隨床單被套忽厚忽薄自動調節燙帶松緊，從而保證熨燙質量。Adopting tension pulley design can adjust the ironing belt tight or loose according to sheep’s thickness to ensure the ironing quality.
6、 機器兩邊箱體采用進口數控激光加工，保證了所有導布棍的平行度，同心度，使設備運行更加平穩。The cabinet sheet made by imported numerical CNC laser cutting machine guarantee depth of parallelism, assured the stable operation performance.
7、 設備有蒸汽加熱、電加熱等機型可供選擇。Steam heating, electric heating are available.
型號規格 Model | Y2000 | Y2500 | Y3000 | Y3000 II | Y3000 III |
燙棍長度 (mm) Length of roller | 2000 | 2500 | 3000 | 3000 | 3000 |
燙棍直徑 (mm) Diameter of roller | 500 | 800 | 800 | 800 | 800 |
熨燙速度 (m/min) Ironing speed | 0~6 | 0~10 | 0~12 | 0~25 | 0~30 |
電機功率 (kw) Motor power | 1.5 | 1.5 | 2.2 | 2.23 | |
電加熱型功率 (kw) Electric heating power | 18 | 24 | 36 | ___ | ____ |
蒸汽型壓力 (Mpa) Steam pressure | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6
| 0.4-0.6 |
整機重量 (kg) Overall weight | 800 | 1000 | 1200 | 2000 | 3000 |
外形尺寸 (mm) Exterior dimension | 1000*1300*3200 | 1200*1400*3800 | 1300*1400*4300 | 2400*1500*4300 | 3600*1500*43008 |
