P系列全封閉干洗設備,適用于賓館、醫院、服裝廠及個體洗衣染業,用于洗滌棉、毛、呢絨、化纖、羽絨等。中高檔衣物織品,使用萃取效能很低,洗凈度高,去污徹底,不操作衣物,洗滌后不褪色,不收縮,無皺折且能防蟲蛀。
1、 采用進口制冷目收系統,并配備制冷機循環和水冷卻兩種制冷目收系統目收溶劑,不銹鋼無接縫管路保證了洗滌過程是在完全封閉的環境中進行,機體內的動態平衡裝置使用道阻力減少,且無死角,極大地提高了目收效率。Use of imported cooling system, and equipped with refrigeration and water cooling two kinds of cooling system received the system received solvent, stainless steel seamless pipe to ensure that the washing process is completely closed in the environment, the body of the dynamic balance device The use of road resistance to reduce, and no dead ends, greatly improving the efficiency of the target.
2、 環保尼龍過濾器,活性炭過濾器,多重過濾既保持了溶劑的清潔度,又不需加硅藻土就能去除溶劑中的色素,從而有效地提高了織物的洗凈度。Environmental protection nylon filter, activated carbon filter, multiple filter both to maintain the cleanliness of the solvent, without adding diatomaceous earth will be able to remove the pigment in the solvent, thereby effectively improving the fabric cleanliness.
3、 雙重過濾,降低蒸餾頻率,蒸餾能耗低,目收裝置能夠深度目收,四氯乙烯損耗更低,運行成本更低。Double filtration, reduce the distillation frequency, low distillation energy consumption, the main collection device to the depth of the main income, lower consumption of tetrachlorethylene, lower operating costs.
4、 全電腦操作系統,預置10套程序,可自行編程,能精確控制洗滌、烘干、洗液還原、衣物柔軟及纖維復原整個干洗程序,使洗滌更有針對性,更有效。Full computer operating system, preset 10 sets of procedures, can be programmed, can accurately control the washing, drying, lotion reduction, soft clothing and fiber recovery throughout the dry cleaning process, so that washing more targeted and more effective.
型號規格 Model | P10 | P12 | P15 | P20 | P25 |
洗滌量 (kg) Capacity of washing | 8~10 | 10~12 | 12~15 | 15~20 | 20~25 |
電源 (v) voltage | 220.380 | 220.380 | 220.380 | 220.380 | 220.380 |
電機功率 (kw) Voltage | 0.4\1.5 | 0.4\1.5 | 0.4\2.2 | 0.75\3 | 0.75\4 |
風機功率 (kw) Motor Power | 0.75 | 0.75 | 1.1 | 1.5 | 1.5 |
液泵功率 (kw) Pump power | 0.55 | 0.55 | 0.75 | 1 | 1.5 |
過濾器電機功率 (kw) Filter motor power | 0.37 | 0.37 | 0.5 | 0.5 | 0.75 |
蒸汽壓力 (mpa) Steam pressure | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 |
整機重量 (kg) Overall weight | 1300 | 1500 | 1800 | 2200 | 3200 |
外形尺寸 (mm) Exterior dimension | 2080*1090*1575 | 2080*1200*1575 | 2080*1300*1750 | 2080*1350*1800 | 2080*1400*1800 |
